Briggs Stratton 20M312 3007 F1 Snow Engine

Briggs Stratton 20M312 3007 F1 Snow Engine
Briggs & Stratton 20M312 3007 F1 is a 208cc, single-cylinder, air-cooled, 4-stroke engine designed for snow blowers and other snow removal equipment. Producing 6.75 horsepower, it is built for reliable performance in cold weather conditions.

BRAND
Briggs Stratton

MODEL NUMBER
20M312-3007-F1

WARRANTY
2 Year

SHIPPING WEIGHT
62

DISPLACEMENT
305cc

STARTER TYPE
Recoil w/ Mit Grip

CRANKSHAFT ORIENTATION
Horizontal

CRANKSHAFT TYPE
Straight

FUEL SYSTEM
Gasoline

CRANKSHAFT DIMENSIONS
1″ x 3-21/32″

CRANKSHAFT LENGTH
3-21/32″

CRANKSHAFT END TAPPED SIZE
7/16 – 20

CRANKSHAFT ROTATION DIRECTION (FROM PTO SIDE)
Counterclockwise

BEARING TYPE
Flange Mount Plain with Oil Seal & Pilot

CYLINDERS
1

CYLINDER BORE TYPE
Aluminum Alloy

FUEL TANK
Yes

FUEL PUMP
No

OIL CAPACITY
28

LOW OIL ALERT
No

LOW OIL SHUTDOWN
No

IGNITION SYSTEM
Electronic

CARBURETOR TYPE
Float

CHOKE CONTROL
Manual

MAX RPM
3600

CHARGING SYSTEM
None

FLYWHEEL
Heavy

PTO HEIGHT
4 – 11/64
