Kohler Courage Engine 196cc 3 4in x 2 7 16in Shaft Model PASH2653011

Kohler Courage Engine 196cc 3 4in x 2 7 16in Shaft Model PASH2653011

Brand
Kohler Engines

Manufacturer’s Warranty
2 Year

Ship Weight
44.0 lbs

Engine Displacement
196 cc

Engine Type
Courage

Start Type
Recoil

Shaft Diameter
3/4 in

Shaft Length
2.43 in

Net Torque
10.2 ft-lbs.

Shaft Output
Counterclockwise

Shaft Keyway
0.18 in

Shaft End Tapped (Diameter (in.)/Threads per inch)
5/16-24 UNF

Shaft Rotation (From PTO Shaft Side)
Counterclockwise

Crankshaft
Hardened

PTO Height
4.17 in

Bearing Type
Ball

Cylinders (qty.)
1

Compression Ratio
8.5 : 1

Cooling System
Air cooled

Bore
2.7 in

Stroke
2.1 in

Air Cleaner Type
Dual element

Fuel Tank
Yes

Fuel Type
Gasoline

Fuel Tank Capacity
3.8 qt

Fuel Filter
Yes

Oil Capacity
0.63 qt

Low Oil Alert
Yes

Low Oil Shutdown
Yes

Lubrication System
Splash

Ignition System
Electronic

Governor System
Mechanical

Carburetor
Bowl drain

Throttle Control
On engine

Choke Control
Yes

Max. RPM
3,600

Muffler Included
Yes

Auto Compression Release
Yes

CARB Approval
Yes

Bolt Circle
3.625 in

Mounting Base Length
6.378 in

Mounting Base Width
3.17 in

Dimensions L x W x H (in.)
12.31 x 14.31 x 13.5 in
