Phasor K3-8.0KW – 8kW 60 Hz Marine Diesel Generator -1800 RPM – Compact Series

Phasor K3-8.0KW – 8kW (60 Hz) Marine Diesel Generator -1800 RPM – Compact Series

Kubota Model
D1005-E4BG

Number of Cylinders
3

Cubic Inch Displacement
61

Fuel Consumption ( Gal/Hr )
Full Load 0.74 Half Load 0.32

Electric End
Coliseum

8.0 Kw
60 Hz

Bore x Stroke
 2.99 x 2.90

Dimensions (LxWxH) without enclosure
 L 26.5″ x W 18.0″ x H 22.5″

 Dimensions (LxWxH) with enclosure
 30″ x 22″ x 25.75″

Weight (lbs.)
386

Output (volts)
120/240

 Output (amps)
66/33

Output (watts)
8,000

 Exhaust Dia.
2.0″

Raw Water Dia.
3/4″

Fuel Line Dia.
5/16″

Return Line Dia.
3/16″
